쿠버네티스 대시보드 설치 (Centos7.9)

이전에 설치한 쿠버네티스 클러스터를 쉽게 관리하기 위한 쿠버네티스 대시보드 설치 내용에 대한 포스팅입니다.

1. 쿠버네티스 대시보드 설치



1-1. 대시보드 설치

- 쿠버네티스 대시보드 설치

$ kubectl apply -f https://raw.githubusercontent.com/kubernetes/dashboard/v2.2.0/aio/deploy/recommended.yaml

namespace/kubernetes-dashboard created
serviceaccount/kubernetes-dashboard created
service/kubernetes-dashboard created
secret/kubernetes-dashboard-certs created
secret/kubernetes-dashboard-csrf created
secret/kubernetes-dashboard-key-holder created
configmap/kubernetes-dashboard-settings created
role.rbac.authorization.k8s.io/kubernetes-dashboard created
clusterrole.rbac.authorization.k8s.io/kubernetes-dashboard created
rolebinding.rbac.authorization.k8s.io/kubernetes-dashboard created
clusterrolebinding.rbac.authorization.k8s.io/kubernetes-dashboard created
deployment.apps/kubernetes-dashboard created
service/dashboard-metrics-scraper created
Warning: spec.template.metadata.annotations[seccomp.security.alpha.kubernetes.io/pod]: deprecated since v1.19, non-functional in v1.25+; use the "seccompProfile" field instead
deployment.apps/dashboard-metrics-scraper created



1-2. 외부 접근 방법 변경

외부에서 쿠버네티스 대시보드를 접근 하는 방법을 기존 Cluster IP에서 NodePort로 변경해줍니다.



- 쿠버네티스 대시보드 외부 접근(NodePort) 설정

kubernetes-dashboard 편집 -> type 부분을 Cluster IP에서 NodePort로 변경

$ kubectl -n kubernetes-dashboard edit service kubernetes-dashboard

# Please edit the object below. Lines beginning with a '#' will be ignored,
# and an empty file will abort the edit. If an error occurs while saving this file will be
# reopened with the relevant failures.
#
apiVersion: v1
kind: Service
metadata:
  annotations:
    kubectl.kubernetes.io/last-applied-configuration: |
      {"apiVersion":"v1","kind":"Service","metadata":{"annotations":{},"labels":{"k8s-app":"kubernetes-dashboard"},"name":"kubernetes-dashboard","namespace":"kubernetes-dashboard"},"spec":{"ports":[{"port":443,"targetPort":8443}],"selector":{"k8s-app":"kubernetes-dashboard"}}}
  creationTimestamp: "2022-04-18T05:02:03Z"
  labels:
    k8s-app: kubernetes-dashboard
  name: kubernetes-dashboard
  namespace: kubernetes-dashboard
  resourceVersion: "4504"
  uid: 87e523dd-2599-473c-aa17-3b2284998828
spec:
  clusterIP: 10.111.218.155
  clusterIPs:
  - 10.111.218.155
  internalTrafficPolicy: Cluster
  ipFamilies:
  - IPv4
  ipFamilyPolicy: SingleStack
  ports:
  - port: 443
    protocol: TCP
    targetPort: 8443
  selector:
    k8s-app: kubernetes-dashboard
  sessionAffinity: None
  type: NodePort
status:
  loadBalancer: {}



- NodePort 확인(master node)

확인 결과 대시보드 포트는 31655이며, 웹 브라우저로 접근 시 활용합니다.

$ kubectl -n kubernetes-dashboard get service kubernetes-dashboard

NAME                   TYPE       CLUSTER-IP       EXTERNAL-IP   PORT(S)         AGE
kubernetes-dashboard   NodePort   10.111.218.155   <none>        443:31655/TCP   3m17s





1-3. 쿠버네티스 대시보드 접근

- 대시보드 접근

대시보드 URL : https://192.168.0.1:31655

#https://<master_ip>:<NodePort>





- 쿠버네티스 로그인 토큰 생성

$ cat <<EOF | kubectl create -f -
>  apiVersion: v1
>  kind: ServiceAccount
>  metadata:
>    name: admin-user
>    namespace: kube-system
> EOF
serviceaccount/admin-user created​



- ClusterRoleBinding 생성

$ cat <<EOF | kubectl create -f -
>  apiVersion: rbac.authorization.k8s.io/v1
>  kind: ClusterRoleBinding
>  metadata:
>    name: admin-user
>  roleRef:
>    apiGroup: rbac.authorization.k8s.io
>    kind: ClusterRole
>    name: cluster-admin
>  subjects:
>  - kind: ServiceAccount
>    name: admin-user
>    namespace: kube-system
> EOF
clusterrolebinding.rbac.authorization.k8s.io/admin-user created





- 사용자 계정의 토큰 호출

$ kubectl -n kube-system describe secret $(kubectl -n kube-system get secret | grep admin-user | awk '{print $1}')

Name:         admin-user-token-gfrxg
Namespace:    kube-system
Labels:       <none>
Annotations:  kubernetes.io/service-account.name: admin-user
              kubernetes.io/service-account.uid: 2d57903d-bc4d-41e8-af86-5695ad6a3ba6

Type:  kubernetes.io/service-account-token

Data
====
ca.crt:     1099 bytes
namespace:  11 bytes
token:      eyJhb~~~



- 웹 대시보드

쿠버네티스 대시보드 -> 검색창 항목에 '모든 네임스페이스' 선택합니다.
